Service Writer: Zach Schroeder Warranty: All parts and labor guaranteed for a period of one year from purchase, mileage unlimited. Guarantee void if abuse or lack of reasonable maintenance is indicated. Processing fees: $12.80 Labor Service - Inspect - Technician took a sample of the rear diff fluid that has been in the vehicle for ~500 miles. Fluid was not burnt, had a decent color, and no major debris was present. However, there was a noticable amount of metal particles in the fluid and on a magnet dipped into the sample. This shows that there is excessive wear happening internal to the differential due to damaged/worn parts. New rear differential assembly is the only correction to internal differential damage, no rebuild is available. Labor Service - Four wheel alignment - Current alignment spec could be overly toed in causing instability. Perform more neutral alignment. Invoice #: 24519. Discard old parts. Original Estimate: XConsumer acknowledges receipt of goods and/or services in the amount shown hereon and agrees to perform the obligations set forth by the card member’s agreement with the issuer. I hereby authorize the repair work listed herein, including sublet work, to be done along with necessary materials. You and your employees may operate the described vehicle for the purposes of testing, inspection or delivery at my risk. An express lien is acknowledged on said vehicle to secure the amount of repairs thereto. You will not be held responsible for loss or damage to vehicle or articles left in vehicle in case of fire, theft, accident or any other cause beyond your control. Customer agrees to pay all collection costs and /or attorneys fees in the event that default is made in any payment due. If vehicle is returned to customer without repair service being performed, a diagnostic and handling fee (including reassembly) may be charged. I have read and understand the above and acknowledge receipt of an estimate. Terms: CASH unless arrangements made prior to authorization. Vehicles left after repair is completed may be subject to a storage fee.

Differential Leak- Repair rear half shaft seal., Labor Service - Replace item(s) replace customer supplied driver side diff seal. Dissasembled driver side suspension arms and brakes to access drive shaft. Upon reassembley while torqueing the bolts, the toe arm bolt pulled the threads from the steering knuckle on the 90 degree final rotation. After removal it was apparant that the whole had had an previously attempted repair. Had to drill and thread whole for a thread insert which held torque. Diff is a little noise to me customer said that he had never noticed anything so we are gonna ship the vehicle and if the noise is to much, the customer will return for further diag., Processing Fee

Total alignment — rear camber corrected from -1.7°/-2.05° to -1.0°/-0.7°. Rear total toe corrected from 0.15° to 0.35°.

AES ran a steering adaptation (from my MHD) and checked all the steering/suspension components.

Alerted yesterday after driving to Cheyenne, WY and back

Used api, kept oems for rebuild
